ACH580-01-145A-4+B056 - IP55 Variable Frequency Drive 75 Kw | ABB Inverter

The complete line of ABB Inverters, Variable Frequency drives and Variable Speed drives for your HVAC system is available at IACS.

The ABB drive ACH580-01-145A-4+B056 is the effective solution for your HVAC system.

The Power Rating of this Inverter is 75 kW.

The IP Rating is IP55.

This is a Three Phase drive.

If you need technical assistance, consult the ABB manualsheet or get in touch with our IACS technical support staff.

ACH580-01-145A-4+B056 - IP55 Variable Frequency Drive 75 Kw Inverter:

has functionality for pumps and fans, such as pump and fan control. includes unified height and depth, pipe cleaning, and filling features. It was built with an energy efficiency counter, an energy optimizer, and a load analyzer for the drive, motor, and process's optimal dimensioning. Additionally, a Flash Drop tool is included for quick parameter tuning.

Powerful and native communications
By removing more parts and wires, embedded HVAC communications methods reduce costs. There aren't any additional fees or useless alternatives. You can administer applications, submit findings, read and write I/O settings, and perform native diagnostics via embedded BACnetMS/TP and other HVAC protocols. Your teams do not require additional training for the new terms or functionalities. The difference between any controller and our drive wouldn't even be apparent.

Loop controllers standard
For precise control of motors, fans, and pumps in HVAC applications, the drive offers a PID loop controller with two configuration options. Additionally, four external PID loop controllers are provided, which can be utilised for various external devices like dampers for changeable air volume or cooling and heating valves.

Native BACnet/IP option
Similar to BACnet MS/TP, no gateways or routers are required. This extra 2-port option lowers the risk of failure and speeds up setting.

75 kW Rated Inverter
FLC 145 Amps Continuous Supply
Power Supply 380 to 480 V, 3ph, 48 to 63 Hz
Dimensions 726mmh, 252mmw, 380mmd
ABB Frame size R6 (IP55)
Weight 46kg
With EMC filter built in as standard

Inputs and Outputs:
2 Analogue I/Ps: (0/2-10v or 0/4-20mA or a Potenziometer)
2 Analogue O/P:(0-10v or 0-20mA)
6 Digital I/Ps
3 Digital O/Ps: (3 relay)
