The ABB drive ACH580-01-088A-4+B056 is the reliable solution for your HVAC system.

The Power Rating of this Inverter is 45 kW.

The IP Rating is IP55.

This is a Three Phase drive.

For technical advice, refer to the ABB manualsheet and contact our IACS technical support team.

ACH580-01-088A-4+B056 - IP55 Variable Frequency Drive 45 Kw Inverter:

has features for pumps and fans, such as control for the pumps and fans. incorporates capabilities for pipe cleaning, filling, and unified height and depth. It was designed with an energy efficiency counter, an energy optimizer, and a load analyzer for the best possible sizing of the drive, motor, and process. A Flash Drop tool is additionally included for easy parameter adjustment.

Powerful and native communications
Embedded HVAC communications techniques lower costs by eliminating extra parts and wires. There aren't any unnecessary extra costs or options. Through embedded BACnetMS/TP and other HVAC protocols, you may manage applications, submit findings, read and write I/O settings, and carry out native diagnostics. For the new words or functionalities, your teams don't need any more training. Any controller and our drive wouldn't even be distinguishable from one another.

Loop controllers standard
For precise control of motors, fans, and pumps in HVAC applications, the drive offers a PID loop controller with two configuration options. Additionally, four external PID loop controllers are provided, which can be utilised for various external devices like dampers for changeable air volume or cooling and heating valves.

Native BACnet/IP option
There are no gateways or routers needed, similar to BACnet MS/TP. With this additional 2-port option, setup is quicker and there are fewer potential failure points.

45 kW Rated Inverter
FLC 88 Amps Continuous Supply
Power Supply 380 to 480 V, 3ph, 48 to 63 Hz
Dimensions 732mmh, 203mmw, 320mmd
ABB Frame size R5 (IP55)
Weight 34kg
With EMC filter built in as standard

Inputs and Outputs:
2 Analogue I/Ps: (0/2-10v or 0/4-20mA or a Potenziometer)
2 Analogue O/P:(0-10v or 0-20mA)
6 Digital I/Ps
3 Digital O/Ps: (3 relay)
