ACH580-01-106A-4+B056 - IP55 Variable Frequency Drive 55 Kw | ABB Inverter

At IACS, you can find the whole range of ABB Inverters, Variable Frequency drives and Variable Speed drives for your HVAC system.

The ABB drive ACH580-01-106A-4+B056 is the suitable solution for your HVAC system.

The Power Rating of this Variable Frequency drive is 55 kW.

The IP Rating is IP55.

This is a 3 Phase drive.

Consult the ABB manualsheet and get in touch with our IACS technical support team for technical guidance.

ACH580-01-106A-4+B056 - IP55 Variable Frequency Drive 55 Kw Inverter:

incorporates functions for the pump and fan, such as control over the pump and fan. consisting of processes for pipe cleaning and filling, as well as unified height and depth. It was constructed with a load analyzer, an energy optimizer, and an energy efficiency counter for load-optimized drive, motor, and process sizing. It also includes a Flash Drop tool for rapid parameter tuning.

Powerful and native communications
By removing more parts and wires, embedded HVAC communications methods reduce costs. There aren't any additional fees or useless alternatives. You can administer applications, submit findings, read and write I/O settings, and perform native diagnostics via embedded BACnetMS/TP and other HVAC protocols. Your teams do not require additional training for the new terms or functionalities. The difference between any controller and our drive wouldn't even be apparent.

Loop controllers standard
A PID loop controller with two configuration options is provided by the drive for accurate control of motors, fans, and pumps in HVAC applications. Four external PID loop controllers are also offered, which can be used for a variety of external devices like cooling and heating valves or dampers for variable air volume.

Native BACnet/IP option
Similar to BACnet MS/TP, no gateways or routers are required. This additional 2-port option speeds up setup and reduces potential failure sites.

55 kW Rated Inverter
FLC 106 Amps Continuous Supply
Power Supply 380 to 480 V, 3ph, 48 to 63 Hz
Dimensions 732mmh, 203mmw, 320mmd
ABB Frame size R5 (IP55)
Weight 34kg
With EMC filter built in as standard

Inputs and Outputs:
2 Analogue I/Ps: (0/2-10v or 0/4-20mA or a Potenziometer)
2 Analogue O/P:(0-10v or 0-20mA)
6 Digital I/Ps
3 Digital O/Ps: (3 relay)
