ACH580-01-169A-4+B056 - IP55 Variable Frequency Drive 90 Kw | ABB Inverter

Find all of the ABB Inverters, Variable Frequency drives and Variable Speed drives you need for your HVAC system at IACS.

The ABB drive ACH580-01-169A-4+B056 is the reliable solution for your HVAC system.

The Power Rating of this Variable Frequency drive is 90 kW.

The IP Rating is IP55.

This is a 3 Phase drive.

For technical advice, refer to the ABB manualsheet and contact our IACS technical support team.

ACH580-01-169A-4+B056 - IP55 Variable Frequency Drive 90 Kw Inverter:

features a pump and fan, such as a control for the pump and fan. includes functions for filling and cleaning pipes as well as uniform height and depth. It was constructed with an energy efficiency counter, an energy optimizer, a load analyzer, and other features for the best possible sizing of the drive, motor, and process. A Flash Drop tool is also included for quick parameter tuning.

Powerful and native communications
HVAC communications protocols that are embedded save money by eliminating extra parts and wires. There are no extra costs or pointless options. Through embedded BACnetMS/TP and other HVAC protocols, you are able to manage applications, submit findings, read and write I/O settings, and carry out native diagnostics. Your teams don't need to be retrained for new terminology or features. Any controller's variation from our drive wouldn't even be noticeable.

Loop controllers standard
The drive comes with a PID loop controller that has two configuration settings and may be set up to operate motors, fans, and pumps in HVAC applications with finer precision. Furthermore, it offers four external PID loop controllers that can be applied to various external devices, such as dampers for variable air volume or cooling and heating valves.

Native BACnet/IP option
There are no gateways or routers required, similar to BACnet MS/TP. Reduce failure spots and shorten configuration time with the additional 2-port option.

90 kW Rated Inverter
FLC 169 Amps Continuous Supply
Power Supply 380 to 480 V, 3ph, 48 to 63 Hz
Dimensions 880mmh, 284mmw, 381mmd
ABB Frame size R7 (IP55)
Weight 56kg
With EMC filter built in as standard

Inputs and Outputs:
2 Analogue I/Ps: (0/2-10v or 0/4-20mA or a Potenziometer)
2 Analogue O/P:(0-10v or 0-20mA)
6 Digital I/Ps
3 Digital O/Ps: (3 relay)
