The ABB drive ACH580-01-04A1-4+B056 is the reliable solution for your HVAC system.

The Power Rating of this Inverter is 1.5 kW.

The IP Rating is IP55.

This is a Three Phase drive.

For technical advice, refer to the ABB manualsheet and contact our IACS technical support team.

ACH580-01-04A1-4+B056 - IP55 Variable Frequency Drive 1.5 Kw Inverter:

has functionality for pumps and fans, such as pump and fan control. includes unified height and depth, pipe cleaning, and filling features. It was built with an energy efficiency counter, an energy optimizer, and a load analyzer for the drive, motor, and process's optimal dimensioning. Additionally, a Flash Drop tool is included for quick parameter tuning.

Powerful and native communications
By removing more parts and wires, embedded HVAC communications methods reduce costs. There aren't any additional fees or useless alternatives. You can administer applications, submit findings, read and write I/O settings, and perform native diagnostics via embedded BACnetMS/TP and other HVAC protocols. Your teams do not require additional training for the new terms or functionalities. The difference between any controller and our drive wouldn't even be apparent.

Loop controllers standard
The drive comes with a PID loop controller that has two configuration settings and may be set up to operate motors, fans, and pumps in HVAC applications with finer precision. Furthermore, it offers four external PID loop controllers that can be applied to various external devices, such as dampers for variable air volume or cooling and heating valves.

Native BACnet/IP option
Similar to BACnet MS/TP, no gateways or routers are required. This additional 2-port option speeds up setup and reduces potential failure sites.

1.5 kW Rated Inverter
FLC 4 Amps Continuous Supply
Power Supply 380 to 480 V, 3ph, 48 to 63 Hz
Dimensions 303mmh, 125mmw, 222mmd
ABB Frame size R1 (IP55)
Weight 5.1kg
With EMC filter built in as standard

Inputs and Outputs:
2 Analogue I/Ps: (0/2-10v or 0/4-20mA or a Potenziometer)
2 Analogue O/P:(0-10v or 0-20mA)
6 Digital I/Ps
3 Digital O/Ps: (3 relay)
