NV24A-SZ-TPC - Belimo Modulating globe valve actuator for 2-way and 3-way globe valves | ideal for globe valves

For any Belimo Actuators that are in stock at iacs, we offer Free Delivery and Next 1-2 Day Delivery.

The Belimo NV24A-SZ-TPCis a kind of Actuator used to operate valves in HVAC applications and systems.

The force applied by the Torque of the NV24A-SZ-TPC is 1000 N.

This Valve Actuator needs to be supported by a power supply of 24Vac/Vdc.

You may utilise this Belimo component with Globe Valves.

Find at IACS the ideal Belimo Actuator compatible with your system at the best price.

If you are unsure about size or installation, refer to the Belimo custom datasheet above or message iacs to receive special instructions and a custom quote.

NV24A-SZ-TPC
Globe valve actuator
1000 N, 20 mm,
AC/DC 24 V, modulating
Operating range DC (0) 0.5...10 V
Position feedback DC (0) 0.5...10 V
Actuating time motor 150 s / 20 mm
IP 54, Manual override temporary, permanent
Connection Terminal with cable PVC 1 m

NV24A-SZ-TPC

Globe valve actuator
1000 N, 20 mm,
AC/DC 24 V, modulating
Operating range DC (0) 0.5...10 V
Position feedback DC (0) 0.5...10 V
Actuating time motor 150 s / 20 mm
IP 54, Manual override temporary, permanent
Connection Terminal with cable PVC 1 m
