ACH580-01-07A3-4 - IP21 Variable Frequency Drive 3 Kw | ABB Inverter

The complete line of ABB Inverters, Variable Frequency drives and Variable Speed drives for your HVAC system is available at IACS.

The ABB drive ACH580-01-07A3-4 is the effective solution for your HVAC system.

The Power Rating of this Inverter is 3 kW.

The IP Rating is IP21.

This is a Three Phase drive.

If you need technical assistance, consult the ABB manualsheet or get in touch with our IACS technical support staff.

ACH580-01-07A3-4 - IP21 Variable Frequency Drive 3 Kw Inverter:

incorporates a pump and fan, as well as a pump and fan control. features uniform height and depth, as well as filling and cleaning functions for pipes. For the best possible sizing of the drive, motor, and process, it was built with an energy efficiency counter, an energy optimizer, a load analyzer, and other features. Also included is a Flash Drop tool for easy parameter adjustment.

Powerful and native communications
Embedded HVAC communications methods reduce costs by removing unnecessary parts and wires. There are no additional fees or needless choices. You can manage applications, report findings, read and write I/O settings, perform native diagnostics, and control various HVAC protocols such as embedded BACnetMS/TP. For new terms or features, your teams do not require retraining. There would be no discernible difference between any controller and our drive.

Loop controllers standard
For precise control of motors, fans, and pumps in HVAC applications, the drive offers a PID loop controller with two configuration options. Additionally, four external PID loop controllers are provided, which can be utilised for various external devices like dampers for changeable air volume or cooling and heating valves.

Native BACnet/IP option
Similar to BACnet MS/TP, no gateways or routers are required. This additional 2-port option speeds up setup and reduces potential failure sites.

3kW Rated Inverter
FLC 7.2 Amps Continuous Supply
Power Supply 380 to 480 V, 3ph, 48 to 63 Hz
Dimensions 303mmh, 125mmw, 223mmd
ABB Frame size R1 (IP21)
Weight 4.6kg
With EMC filter built in as standard

Inputs and Outputs:
2 Analogue I/Ps: (0/2-10v or 0/4-20mA or a Potenziometer)
2 Analogue O/P:(0-10v or 0-20mA)
6 Digital I/Ps
3 Digital O/Ps: (3 relay)
