ACH580-01-062A-4 - IP21 Variable Frequency Drive 30 Kw | ABB Inverter

At IACS, you can find the whole range of ABB Inverters, Variable Frequency drives and Variable Speed drives for your HVAC system.

The ABB drive ACH580-01-062A-4 is the suitable solution for your HVAC system.

The Power Rating of this Inverter is 30 kW.

The IP Rating is IP21.

This is a Three Phase drive.

Consult the ABB manualsheet and get in touch with our IACS technical support team for technical guidance.

ACH580-01-062A-4 - IP21 Variable Frequency Drive 30 Kw Inverter:

includes pump and fan features, such as control over the pump and the fan. consisting of unified height and depth, pipe cleaning, and filling operations. In addition to a load analyzer for load-optimized drive, motor, and process sizing, it was built with an energy efficiency counter and an energy optimizer. For quick parameter setting, it also comes with a Flash Drop tool.

Powerful and native communications
HVAC communications protocols that are embedded save money by eliminating extra parts and wires. There are no extra costs or pointless options. Through embedded BACnetMS/TP and other HVAC protocols, you are able to manage applications, submit findings, read and write I/O settings, and carry out native diagnostics. Your teams don't need to be retrained for new terminology or features. Any controller's variation from our drive wouldn't even be noticeable.

Loop controllers standard
For precise control of motors, fans, and pumps in HVAC applications, the drive offers a PID loop controller with two configuration options. Additionally, four external PID loop controllers are provided, which can be utilised for various external devices like dampers for changeable air volume or cooling and heating valves.

Native BACnet/IP option
There are no gateways or routers needed, much like BACnet MS/TP. This extra 2-port option decreases potential failure sites and speeds up setting.

30kW Rated Inverter
FLC 62 Amps Continuous Supply
Power Supply 380 to 480 V, 3ph, 48 to 63 Hz
Dimensions 600mmh, 203mmw, 257mmd
ABB Frame size R4 (IP21)
Weight 19kg
With EMC filter built in as standard

Inputs and Outputs:
2 Analogue I/Ps: (0/2-10v or 0/4-20mA or a Potenziometer)
2 Analogue O/P:(0-10v or 0-20mA)
6 Digital I/Ps
3 Digital O/Ps: (3 relay)
