ACH580-01-02A7-4 - IP21 Variable Frequency Drive 0.75 Kw | ABB Inverter

At IACS, you can find the whole range of ABB Inverters, Variable Frequency drives and Variable Speed drives for your HVAC system.

The ABB drive ACH580-01-02A7-4 is the suitable solution for your HVAC system.

The Power Rating of this Inverter is 0.75 kW.

The IP Rating is IP21.

This is a Three Phase drive.

Consult the ABB manualsheet and get in touch with our IACS technical support team for technical guidance.

ACH580-01-02A7-4 - IP21 Variable Frequency Drive 0.75 Kw Inverter:

contains features for fans and pumps, including controls for the fans and pumps. includes features for pipe filling, cleaning, and unified height and depth. For the best possible sizing of the drive, motor, and process, it was developed with an energy efficiency counter, an energy optimizer, and a load analyzer. For simple parameter tweaking, a Flash Drop tool is also provided.

Powerful and native communications
HVAC communications protocols that are embedded save money by eliminating extra parts and wires. There are no extra costs or pointless options. Through embedded BACnetMS/TP and other HVAC protocols, you are able to manage applications, submit findings, read and write I/O settings, and carry out native diagnostics. Your teams don't need to be retrained for new terminology or features. Any controller's variation from our drive wouldn't even be noticeable.

Loop controllers standard
The drive provides a PID loop controller with two configuration options for accurate control of motors, fans, and pumps in HVAC applications. There are also four external PID loop controllers that can be used for a variety of external devices, such as dampers for variable air volume or cooling and heating valves.

Native BACnet/IP option
There are no gateways or routers needed, much like BACnet MS/TP. This extra 2-port option decreases potential failure sites and speeds up setting.

0.75kW Rated Inverter
FLC 2.5 Amps Continuous Supply
Power Supply 380 to 480 V, 3ph, 48 to 63 Hz
Dimensions 303mmh, 125mmw, 210mmd
ABB Frame size R1 (IP21)
Weight 4.5kg
With EMC filter built in as standard

Inputs and Outputs:
2 Analogue I/Ps: (0/2-10v or 0/4-20mA or a Potenziometer)
2 Analogue O/P:(0-10v or 0-20mA)
6 Digital I/Ps
3 Digital O/Ps: (3 relay)
