QFM2160 - Siemens Duct sensor for humidity (DC 0...10 V) and temperature (DC 0...10 V)

Visit iacs to find every part of your HVAC system. In stock Siemens Humidity, CO2 Air Quality and Temperature Sensors may all be delivered in 5 to 7 working days.

The Siemens QFM2160 is a Sensor that is employed in HVAC solutions and which offers clear Humidity and Temperature measurement.

Values inside ducts are measured using This kind of Sensor.

At iacs, you can get the best Siemens Sensor for your system at the right price.

Consult the Siemens custom datasheet above or contact iacs via email for personal ised ass istance if you have queries about size or installation.

The Siemens QFM2160 Duct Sensor for Humidity and Temperature is an industrial-grade sensor designed to measure both temperature and humidity in ducts. It offers a signal output of DC 0...10 V for both humidity and temperature, making it easy to integrate into a wider control system.

The QFM2160 Duct Sensor is suitable for use in a range of industrial applications, thanks to its robust construction and IP54 degree of protection. It operates on AC 24 V or DC 13.5…35 V and features a screw terminal connection for easy installation.

The QFM2160 Duct Sensor's temperature sensing element provides accurate readings across a wide temperature range of 0…50 °C, -35…35 °C, and -40…70 °C. Meanwhile, its humidity measurement range is 0…95% r.h. with an accuracy of ±3% r.h. at 30…70% r.h. and ±0.6 K at 15…35 °C and 23% r.h.

The QFM2160 Duct Sensor for Humidity and Temperature with 0-10V DC Output has a time constant of 20 seconds for humidity and 210 seconds for air v=2 m/s. It also features an immersion length of 90…154 mm and a flange fixing type for easy installation. The dimensions of the sensor are 80 x 88 x 39 mm.

Overall, the Siemens QFM2160 Duct Sensor for Humidity and Temperature with 0-10V DC Output is a reliable and accurate sensor for industrial applications that require precise temperature and humidity measurement. Its sturdy construction, wide measuring range, and high accuracy make it an ideal choice for HVAC and other industrial processes.
