NRFD230A-3 - Belimo Rotary actuator fail-safe 5 Nm, NC AC 100...240 V, 3-point | ideal for ball valves

At IACS we provide Free Delivery and Next 1-2 day Delivery for all the Belimo Actuators in stock.

The Belimo NRFD230A-3 is an Actuator used in HVAC applications and air ventilation systems.

This type of Actuator applies a Rotary motion to regulate the damper.

The Torque force applied by the NRFD230A-3 is 5 Nm.

The power supply requested for this Rotary Actuator is 230Vac.

Find the appropriate Belimo Actuator for your system at the greatest price at iacs.

If you have questions about size or installation, consult the Belimo custom datasheet above or send an email to iacs to get personalised guidance.

NRFD230A-3 - Rotary actuator fail-safe 5 Nm, NC AC 100...240 V, 3-point

• Rotary actuator fail-safe 5 Nm, NC
• AC 100...240 V, 3-point
• Running time motor 35 s / 90°
• Running time fail-safe <20 s / 90°
• IP54, Manual override No
• Connection Cable 1 m PVC
• Direction of motion motor Y = 0 (A – AB = 0%)

Features


• Mode of operation The actuator moves the ball valve to the operating position at the same time as tensioning the return spring. The ball valve is turned back to the safety position by spring force if the supply voltage is interrupted.


• Simple direct mounting Straightforward direct mounting on the ball valve with only one screw. The mounting position in relation to the ball valve can be selected in 90°<) steps.


• High functional reliability The actuator is overload-proof, requires no limit switches and automatically stops when theend stop is reached.


• Combination valve actuators Refer to the valve documentation for suitable valves, their permitted media temperatures and closing pressures.


•     Electrical data Nominal voltage AC 230 V, 50/60 Hz
•     Nominal voltage range AC 195 ... 264 V
•     Power consumption In operation 4 W @ nominal torque
•     At rest 3 W
•     For wire sizing 15 VA
•     Connection Cable 1 m, 4 x 0.75 mm2
•     Parallel connection Yes (Note performance data for supply!)
•     Functional data Torque Motor Min. 10 Nm @ nominal voltage
•     Spring return Min. 10 Nm
•     Direction of rotation Spring return
•     – NRF230A Deenergised NC, ball valve closed (A – AB = 0%)
•     – NRF230A-O Deenergised NO, ball valve open (A – AB = 100%)
•     Manual override With hand crank and interlocking switch
•     Angle of rotation Max. 90°<)
•     Running time Motor ≤75 s / 90°<)
•     Spring return ≤20 s @ –20 ... 50°C / max. 60 s @ –30°C
•     Sound power level Motor ≤45 dB (A)
•     Spring return ≤62 dB (A)
•     Position indication Mechanical
•     Safety Protection class II totally insulated
•     Degree of protection IP54
•     EMC CE according to 2004/108/EC
•     Low-voltage directive CE according to 2006/95/EC
•     Certification cULus according to UL 60730-1A and UL 60730-2-14 and CAN/CSA E60730-1:02
•     Mode of operation Type 1.AA
•     Rated impulse voltage 4 kV
•     Control pollution degree 3
•     Ambient temperature –30 ... +50°C
•     Media temperature +5 ... +130°C (in ball valve, –10°C with stem heating upon request
•     Non-operating temperature –40 ... +80°C
•     Ambient humidity 95% r.h., non-condensating
•     Maintenance Maintenance-free
•     �imensions / Weight Dimensions See «Dimensions» on page 3
•     Weight Approx. 2 kg (without ball valve)
