NRF24A-SR-O Spring-Return Actuator NO, 10 Nm, AC/DC 24 V, 20 s - Belimo | ideal for ball valves

Find all the components for your ventilation system at IACS. All Belimo Actuators on hand are eligible for Free Delivery and 1-2 Delivery.

The Belimo NRF24A-SR-O is a kind of Actuator used in HVAC applications and air ventilation systems.

The Torque used by the NRF24A-SR-O is 10 Nm.

The power supply requested for this Rotary Actuator is 24Vac/Vdc.

IACS has the best prices on the right Belimo Actuators for your system.

Consult the Belimo custom datasheet above or contact iacs via email for personalised assistance if you have queries about size or installation.

NRF24A-SR-O Spring-Return Actuator NO, 10 Nm, AC/DC 24 V, 20 s

• 10 Nm, 90 s, 90°
• AC/DC 24 V, modulating
• IP 54, Manual Override With Integrated Position Stop
• Running Time Spring < 20 s
• Control DC 0...10 V
• Operating Range DC 2...10 V
• Position Feedback DC 2...10 V
• Connection PVC Cable 1m
• Emergency Control Open
• With Mounting Kit for RKH Mounted

Mode of operation: The actuator is connected with a standard modulating signal DC 0...10 V. The actuator moves the valve to the operating position at the same time as tensioning the return spring. The valve is turned back to the emergency position by spring force when the supply voltage is interrupted.

Direct mounting: Simple direct mounting on the ball valve with only one screw. The mounting orientation in relation to the ball valve can be selected in 90° steps.

Manual override: Manual actuation of the valve with manual elevator crank, engagement with the locking switch at any position. Unlocking is manual or automatic by applying the operating voltage.

High functional reliability: The actuator is overload protected, requires no limit switches and automatically stops when the end stop is reached.

Adjustable angle of rotation: Adjustable angle of rotation with mechanical end stop.

Electrical data:

• Nominal voltage AC/DC 24 V
• Nominal voltage frequency 50/60 Hz
• Nominal voltage range AC 19.2...28.8 V / DC 21.6...28.8 V
• Power consumption in operation 3.5 W
• Power consumption in rest position 2.5 W
• Power consumption for wire sizing 6 VA
• Connection supply / control Cable 1 m, 4 x 0.75 mm²
• Parallel operation Yes (note the performance data)

Functional data:

• Torque motor Min. 10 Nm
• Torque spring return Min. 10 Nm
• Positioning signal Y DC 0...10 V
• Positioning signal Y note Input impedance 100 kΩ
• Operating range Y DC 2...10 V
• Position feedback U DC 2...10 V
• Position feedback U note Max. 0.5 mA
• Position accuracy ±5%
• Direction of rotation motor Y=0 (0V = A-AB = 0%)
• Direction of rotation spring-return Deenergised NO, valve open (A - AB = 100%)
• Manual override By means of hand crank and locking switch
• Angle of rotation 90°
• Running time motor 90 s / 90°
• Running time emergency setting position <20 s / 90°
• Sound power level motor max. 45 dB(A)
• Position indication Mechanical
• Service life Min. 60,000 emergency positions

Safety:

• Protection class IEC/EN III Safety extra-low voltage
• Protection class UL UL Class 2 Supply
• Degree of protection IEC/EN IP54
• Degree of protection NEMA/UL NEMA 2, UL Enclosure Type 2
• EMC CE according to 2004/108/EC
• Certification IEC/EN IEC/EN 60730-1 and IEC/EN 60730-2-14
• Certification UL cULus according to UL 60730-1A, UL 60730-2-14 and CAN/CSA E60730-1:02
• Mode of operation Type 1.AA
• Rated impulse voltage supply / control 0.8 kV
• Control pollution degree 3
• Ambient temperature -30...50°C
• Non-operating temperature -40...80°C
• Ambient humidity 95% r.h., non-condensing
• Maintenance Maintenance-free

Weight: 2 kg
