D6300WL - Belimo 2-way Butterfly Valve, DN 300, Lugged Type, PN16, KVS 1740

All in-stock Belimo Butterfly Valves with iacs are delivered for free or within 1-2 days.

The Belimo D6300WL is a Valve used in HVAC applications (heating, ventilation, and air conditioning) systems as a control or shutdown Valve.

The Pressure Nominal of this Valve is PN 16.

The Valve is known and has a Diameter Nominal ofDN 300.

IACS can help you get the best-priced Belimo Butterfly Valve for your system.

If you have any queries concerning size or installation, please refer to the Belimo custom datasheet above or contact iacs by email.

Features

• Mode of operation The butterfly valve is opened or closed completely by an open-close rotary actuator. Continuous rotary actuators are connected by a commercially available controller and move the valve to any position desired. The valve disk made of stainless steel is pressed into the soft-sealing EPDM seat by a rotary movement and ensures leakage rate A (tight). The pressure losses are slight in the open position and the kv value is at a maximum.


• Manual override Manual throttling or shut-off can be carried out with a worm gear (see «Accessories»). The worm gear with position indication is steplessly adjustable (self-locking).
