AX-RLA-AC - Axio Raise/Lower to Analogue Module 24Vac

AX-RLA-AC - Raise/Lower to Analogue Module 24Vac Features:

• Isolated Raise Lower inputs
• 12 to 24 Vac/dc or volt free inputs
• Raise and lower input LEDs
• 24Vac/dc powered
• Sixteen cycle time options
• Built in triac load resistors
• Override preset for commissioning
• DIN rail carrier (TS35 DIN rail)

AX-RLA-AC - Raise/Lower to Analogue Module 24Vac :

The Axio AX-RLA isolates and converts a raise-lowerinput signal into a 0-10 volt analogue output. The unitprovides sixteen raise-lower cycle times and a manualoutput override for commissioning. The input commoncan be connected to the signal 0V or supply voltageallowing the inputs to be voltages (AC/DC) or switchingsignals. Input load resistors can be selected for triacswitching. The unit also provides a 24V supply feedthrough for valve actuators, etc. to simplify cabling. TheAX-RLA is supplied in a DIN rail carrier suitable formounting on TS35 section DIN rail and features highquality rising clamp terminals for ease of connection.

• Input Signal: 0-10V dc (1mA max)
• Output Contacts: 2 x SPCO
• Contact Rating: 12A @ 250V ac (res.)
• Power Supply: 24V ac or dc
• Supply current: 50 mA dc / 125 mA ac maximum
• Power Consumption: 70mA max@24V ac, 50mA max@24Vdc
• Modes of Operation: Cycle Times: ARL, ARL
• Variable 1: 90 to 300 secs, 10 to 30 secs
• Fixed: 210 secs, 90 secs
• Variable 2: 30 to 150 secs, 60 to 120 secs
• Manual Override: ON/OFF/AUTO (Link Selectable)
• Reset: Automatic 24 hour reset for 115% of range
• Terminals: Rising Clamp for 0.5-2.5mm²Cable
• LED Indicators: ON when relay energised
• Ambient Range: 0 to 50°C
• Dimensions: 83mm (l) x 46mm (w) x 45mm (h) (approx.)
• Weight: 72 g
• Country of Origin: United Kingdom
