AX-PCM2-30i - Axio Dual channel 30VA Phase Cut Module

AX-PCM2-30i - Dual channel 30VA Phase Cut Module Features:

• Dual 30VA 0-20V Phase-cut outputs
• DIN rail carrier as standard (TS35 DIN rail)
• 0-10V control signal inputs
• High quality rising clamp terminals
• Fully opto-isolated
• Integral heatsink

AX-PCM2-30i - Dual channel 30VA Phase Cut Module :

The Axio AX-PCM2-30i converts one or two 0- 10Vdc control input signals to one or two 0-20V, 50Hz phase-cut outputs, at up to 30VA each output. The control circuit of the module is powered from 24Vac or 24Vdc (with a common connection to the input signal). A separate isolated input connection is provided for the 24Vac phase-cut load supply. The AX-PCM2-30i features full opto-isolation of the control signal from the output circuit, to ensure that no grounding conflicts can occur.

• Control Supply Input 24Vac/dc (±15%), at 25mA maximum
• Control Input Supply 0-10Vdc (47k Ω load impedance)
• Phase-Cut Load Supply Input 24Vac, 50Hz rated to drive the load (30VA maximum x 2)
• Phase-Cut Load Signal 0-20V full wave rectified 50Hz phase-cut at 30VA maximum each output
• LED Indicator Provides indication of unit operation (see section on page 2)
• Terminals: Rising Clamp for 0.5-2.5mm² Cable
• Ambient Temp. Range: 0 to 40°C
• Dimensions: 57mm x 85mm x 60mm
• Weight: 70gms
• Country of Origin: United Kingdom
