Z-UIC Belimo Signal Converter Voltage/Current

Visit iacs for further details on each part of your ventilation system.

Currently in stock, all Belimo accessories can be delivered for free or within one to two days.

The Belimo Z-UIC is a Signal Converter Voltage/Current .

The most economical Belimo system accessories are available from Iacs.

If you have any queries about installation or sizing, please refer to the aforementioned Belimo bespoke datasheet. If you require more specialised assistance, please email iacs.

Features

• Signal converter voltage/current
• Supply AC/DC 24 V
• Input 0(2)...10 V or 0(4)...20 mA
• Output 0(4)...20 mA
• without electrical isolation
• max. power output 0.5 W
• IP66, housing with PG threaded connection

Electrical data:

• Nominal voltage AC 24V, 50/60 Hz / DC 24V
• Power supply range AC/DC 19.2...28.8 V
• Connection Spring terminals, max. 1.5 mm2
• Max. 1 lead per terminal opening (cable ∅ 5 ... 10 mm, 4-core)
• Use a screwdriver to install
• Cable gland clamping range 5 ... 10 mm
• Electrical isolation No

Functional data:

• Input impedance (U5 input) >100 kΩ
• Non-linearity < 1%
• Control by controller (controller signal) Selectable with jumper: – Jumper set: 0 ... 20 mA → 0 ... 10 V (factory setting), – Jumper removed: 0 ... 20 mA → 0 ... 20 mA
• Load at 4…20 mA outlet 0 ... 600 Ohm (signal conductor resistance + input resistance controller)

Safety:

• Protection class III Safety extra-low voltage
• Degree of protection IP66
• EMC CE according to 2004/108/EC
• Mode of operation Type 1
• Ambient temperature –30 … +50°C
• Non-operating temperature –40 … +80°C
• Ambient humidity range 95% r.h., non-condensating
• Rated impulse voltage 0.8 kV
• Control pollution degree 3
• Maintenance Maintenance-free

Dimension: See «Dimensions» on page 2
Weight: Approx. 200 g
