SKU
SPKT00B6P0
SPKT00B6P0 - Carel Pressure Transducer 0 to 5 Vdc, 0 to 45 bar
£84.68
£70.57
In stock
Only 5 left
Manuals & Datasheets
| PRODUCT LAUNCH | DATA-SHEET |
 |
|
| Product type | Sensors & Stats |
| IP rating | IP65 |
| Output Signal | 0..5 Vdc |
| Manufacturer | Carel |
| Sensor Type | Gas Pressure Transducer |
| Pressure range | 0 to 50 Bar |
Explore at iacs our full range of Carel Transducers for your HVAC system
The Carel Pressure Transducers now offer superior performance in terms of precision, better support for overpressure, wider operating temperature range, and vibration resistance in addition to being offered in a ratiometric version.
The Carel SPKT00B6P0 is a Sensor Transducer compatible with the following refrigerants: R12, R22, R134A, R404A, R407C, R410A, R502, R507, R744, HFO 1234ze
The Pressure range measured is 0 to 45 bar.
The Power Supply for this Carel transducer is 5Vdc ± 10%.
This Carel transducer uses a Packard-Male connection.
The Index of Protection is IP65, IP67 if with connector.
For technical advice, refer to the Carel manualsheet and contact our iacs technical support team..
|
TECHNICAL FEATURES SPKT*R0 |
|
|
|
|
|
Power supply |
4.5 to 5.5 Vdc |
|
Operating conditions |
-40T120 °C |
|
Output |
0.5 to 4.5 Vdc |
|
Precision |
±1.2% |
|
Temperature error |
±0.013%/°C |
|
Connector thread |
7/16” 20UNF |
|
Index of protection |
IP65 |
