SKU
SM230A

SM230A - Belimo Damper Rotary actuator 20 Nm, 150 s, 95° AC 230 V

£167.16 £139.30
In stock
Only 3 left
Free delivery over £30
Chat with us to find out stock levels
Manuals & Datasheets
 DATA-SHEET
DATASHEET

Product typeActuator
IP ratingIP54
Input SignalOn/Off
ManufacturerBelimo
Power Supply230Vac, 1Ph, 50Hz
Torque20 Nm
Running time140 to 150 sec
Actuator typeRotary
Control TypeOpen/Close

Find all parts for your ventilation system at iacs, the Free Delivery and 1-2 Delivery is available for all the Belimo Actuators in stock

The Belimo SM230A is a type of Actuator used to control dampers in HVAC systems and applications.

This kind of Actuator rotates the damper in order to control it.

The force applied by the Torque of the SM230A is 20 Nm.

This Rotary Actuator needs to be supported by a power supply of 230Vac.

IACS has the best prices on the right Belimo Actuators for your system.

Consult the Belimo custom datasheet above or contact iacs via email for personalised assistance if you have queries about size or installation.

The Belimo SM230A is a damper actuator used to modify air dampers in ventilation and air-conditioning systems.

A rotational motion is generated by this sort of actuator.

The Belimo SM230A has a Open/Close type of control.

The torque force is 20 Nm.

Features


  • Simple direct mounting Simple direct mounting on the damper spindle with a universal spindle clamp, supplied with an anti-rotation strap to prevent the actuator from rotating.
  • Manual override Manual override with push-button possible (the gear is disengaged for as long as the button is pressed or remains locked).
  • Adjustable angle of rotation Adjustable angle of rotation with mechanical end stops.
  • High functional reliability The actuator is overload-proof, requires no limit switches and automatically stops when the end stop is reached.
  • Flexible signalization Flexible signalization with adjustable auxiliary switch (0 ... 100%).

The SM230A Belimo Damper Actuator is an efficient and reliable solution for controlling air flow in HVAC systems. With a nominal voltage range of AC 85-265V and a power consumption of 2.5W in operation and 0.6W at rest, this actuator is designed to be energy-efficient. It also features a 1m cable with a connection size of 3x0.75mm2 for easy installation.

The torque of this actuator is 20Nm at nominal voltage, and it has a reversible direction of rotation with a switch for 0 or 1. Additionally, it has a manual override option with a gearing latch that can be disengaged and locked. The angle of rotation can be limited at both ends with adjustable mechanical end stops and a running time of 150s/90°. The sound power level of this actuator is a maximum of 45dB(A) and it has a mechanical, pluggable position indication. It is also safety rated with protection class II and a degree of protection of IP54 in any mounting position.

This actuator is CE certified according to 2004/108/EC and 2006/95/EC and it is cULus certified according to UL 60730-1A and UL 60730-2-14 and CAN/CSA E60730-1:02. It is rated for impulse voltage of 2.5kV and has a control pollution degree of 3. The ambient temperature range for this actuator is -30°C to +50°C and it can be stored in temperatures of -40°C to +80°C. It also has a humidity range of 95% r.h, non-condensating. This actuator is maintenance-free and has a weight of approximately 1kg. It is suitable for NEMA 2 and UL Enclosure Type 2.
