SAL61.00T10 - Siemens Valve Actuator, 10 Nm | ideal for butterfly valves and slipper valves | Operating Voltage AC/DC 24 V

The Siemens SAL61.00T10 is an electromotoric actuator designed for use in various applications. It is capable of providing a maximum torque of 10 Nm and an angular rotation of 90° for precise control. The actuator is equipped with a power consumption of 5 VA, a positioning time of 120 s and a positioning signal of DC 0…10 V, DC 4…20 mA, 0…1000 Ohm.

It also features a degree of protection of IP54 and an operating voltage of AC/DC 24 V. The actuator is designed for an ambient temperature of -15…55°C and a medium temperature of -10…120°C. It has a compact design with dimensions of 160 x 124 x 153 mm and can be installed in an upright to horizontal position. It also features a position feedback of DC 0…10 V and an auxiliary switch of 0.

The Siemens SAL61.00T10 is the perfect choice for a variety of applications requiring reliable and accurate operation.
