AX-RM4AB - Axio Four Relay Module 4 adjustable switchpoints On & Off

AX-RM4AB - Four Relay Module 4 adjustable switchpoints On & Off Features:

• 0-10Vdc Control input at low current
• 4 adjustable on/off Volt Free Relay Outputs
• Buffered slave 0-10Vdc Output
• LED Indication of Relays
• Auto/On/Off Jumper link for comissioning
• High Quality Rising Clamp Terminals
• DIN Rail Carrier (TS35 DIN Rail)

AX-RM4AB - Four Relay Module 4 adjustable switchpoints On & Off :

The AX-RM4AB provides 4 adjustable switched outputs from a single 0-10Vdc control input. Both the switch on/off points of each relay is adjustable on-board, and a re-buffered 0-10Vdc output mirrors the input to drive for example, another module, this reduces wiring. Auto/On/Off jumper links aids in commissioning and individual LEDs provides information on relay states. TS35 suitable DIN rail carrier and high quality rising clamp terminals guarantee ease of installation.

• Supply voltage: 24Vac or dc (+/-15%)
• Supply current: 180mA on 24Vac / 100mA on 24Vdc maximum
• Input: 0-10Vdc at 0.3mA maximum
• Output: 0-10Vdc at 5mA maximum
• Switch On point: Adjustable 0.1 to 10Vdc
• Switch Off point: Adjustable 0.1 to Switch On point
• Output switching: 4 off Single Pole Changeover - 230Vac at 12 amps (NO contact- Resistive load) max.
• Terminals: Rising clamp for 0.5-2.5mm2 cable
• LED indicators: ON when relay energised
• Ambient temperature range: 0°C to 50°C
• Dimensions: 115(W) x 83(H) x 47(D) mm (Maximum)
• Weight: 160 grams
• Country of origin: United Kingdom
