065Z0216 Danfoss VRB 3 Port Seated Plant valve– 2-way valve internal thread |DN20 VRB3 20/6.3 PN16 KVS 6.3

For district heating and cooling, HVAC, and central heating systems, Danfoss Motorized Control Valves (MCV) guarantee steady and precise fluid control. This boosts the system's energy efficiency while also improving temperature management and dependability.

The Danfoss 065Z0216 is a Seated Plant valve.

This type of valve is composed by 3 ports.

The Pressure Nominal is PN 16.

The Diameter Nominal is DN 20.

Free delivery and delivery within 1-2 days are available for Danfoss products that are currently in stock at iacs.

For more information, refer to the datasheet in the Danfoss Manual.

Features of VRB 2 and VRB 3 Range:
• Bubble tight design
• Snap mechanical connection together with
AMV(E) 335, AMV(E) 435
• Dedicated 2 and 3-port valv
• Suitable for diverting applications (3-port)
Main data:
• DN 15-50
• kVS 0,63-40 m3/h
• PN 16
• Temperature:
- Circulation water / glycolic water up to 50 %:
2 (–10*) … 130 °C
* At temperatures from –10 °C up to +2 °C use stem heater
• Connections:
- Internal thread
